PEGASUS HARD-8MF
Unmanned aerial vehicle
The UAV is suitable for reset any general ammunition weighing up to 50 kg
Max Time flight without loading up to 40 min. Flight altitude before 2000
Airspeed up to 20 m/s in windless environment
Production of modern types of UAVs
Pilot training
Service maintenance
Characteristics
UAV
H A R D - 8 M F
Diagonal length: 1950mm 870mm x 720mm x 640mm (folded) (including propellers)
Propeller size: 43 inches Standard takeoff weight: 42 kg (with batteries)
Maximum payload: up to 50 kg
Maximum takeoff weight: 92 kg (near sea level)
Maximum lifting speed: 5 m/s
Maximum descent speed: 4 m/s
Maximum horizontal flight speed: up to 20 m/s (calm environment)
Wind resistance class: 6-7
Maximum wind speed: 8 m/s
Maximum flight time: 40 minutes (without loading)
Maximum flight altitude: 2000m.
Recommended working environment temperature: 0 to +40 °C
Double camera
T h e r m a l +
Z o o m 3 0
30x camera: 1080P visible light + 640*480 infrared thermal camera
Visible light camera: Image sensor: 1/2.8" Sony CMOS ISO range: 100-3200 (video) / 100-1600 (photo)
Recording resolution: 1080P, 30fps
Photo resolution: 1920 X 1080
Focal Length: 4.7~141mm
Zoom: 30 optical zoom
Dual Speed: Approximately 3.0 seconds Horizontal FOV: 60° - 2.3° (Wide Angle - Range)
Close range: > 5000 mm (wide angle - range)
Compression standard: H.264/H.265
File storage format supported: JPG/MP4
Memory card type: SD/SDHC/SDXC micro-SD card, maximum support 128G, transfer rate Class10 or higher or UHS-1 rating Micro SDW card
Infrared Thermal Imaging Sensor: Amorphous Silicon Infrared Microradiometer
Sensor resolution: 640*480 Focal length 25mm
The pixel size is 17 µm.
Wavelength range 8~14 µm
Temperature measurement accuracy: ±2°C or ±2% (whichever is greater)
Photo Mode: Single Shot, Burst Shot, and Timed Shot
Photo Resolution: Infrared Mode 640*480
Image Format 1920*1080,1280*720
Video resolution 640*480@30 FPS MP4
Video Format (Support H.264/H.265)
Digital system transmission image and remote control
Working frequency: 800Mhz, 1.4Ghz, 2.4Ghz
Maximum image transmission distance: 10km (open, no shielding, no electromagnetic interference)
Modulation mode: OFDM and MIMO
Video code: H.264
Clarity: 1080p60
Medium temperature -10 °C to 40 °C
Ambient temperature for charging: 5°C to 40°C
System positioning
Frequency range:
GPS: L1/L2/L5
GLONASS: F1/F2
BeiDou: B1/B2/B3
Galileo: E1/E5
Operating environment temperature: 0 to 45 °C
Battery
Voltage: 58.8V
Capacity: 64000-96000 mah
Discharge rate: 20S
Battery type: LI NMC 14S
Reset system
Vertical type. Discharge single or simultaneous, for 1-6 mortar ammunition caliber 82 mm, manual and automatic mode (by coordinates)
